Feature:
Pure sine wave output.
Brand new wide LCD screen, clearly and precisely shows working data.
Low frequency toroidal transformer lower loss.
Three -stage charging: Constant current , constant voltage, float charge.
Three types working modes; Battery type selectable.
Added fault code query function, easy to monitor the operation in real time.
Supports RS232 or RS485 communication port.
| specification | ||||||||||
| rated power | 500w | 700w | 1kw | 1.5kw | 2kw | 3kw | 4kw | 5kw | 6kw | 7kw |
| barrery voltage | 12/24VDC | 24/48VDC | 48/96VDC | 96VDC | ||||||
| machine size(L*W*Hmm) | 408*296*130 | 470*316*130 | 560*388*150 | 620*400*181 | ||||||
| packing size(L*W*Hmm) | 495*365*220 | 555*385*220 | 665*460*235 | 700*485*265 | ||||||
| N.W(kg) | 8.5 | 9.5 | 11.5 | 14 | 17 | 20 | 25 | 26 | 30 | 34 |
| G.W(kg) | 10 | 11 | 13 | 16 | 19 | 22 | 27 | 28 | 32 | 36 |
| parameter | ||||||||||
| battery type | sealed battery, gel battery, vented battery etc(base on battery charge specification) | |||||||||
| DC input voltage range | 10.5~15VDC(single battery voltage) | |||||||||
| AC input voltage range | 73VAC~138VAC/93VAC~150VAC/145VAC~275VAC/158VAC~300VAC | |||||||||
| AC input frequency range | 45Hz~65Hz | |||||||||
| efficiency(battery mode) | ≥85% | |||||||||
| out voltage(battery mode) | (110VAC~240VAC)±2% | |||||||||
| out frequency(battery mode) | 56/60Hz±1% | |||||||||
| output wave(battery mode) | pure sine wave | |||||||||
| AC output voltage range | (110VAC~240VAC)±10% | |||||||||
| AC output frequency range | tracking automatically | |||||||||
| workking mode | AC first, battery first, saving energy mode | |||||||||
| AC charging current(selectable) | 0~30A | |||||||||
| solar charging current(selectable) | 10~60A(PMW or MPPT) | |||||||||
| transfer time | ≤4ms | |||||||||
| display | LCD | |||||||||
| thermal method | cooling fan in temperature comtrol | |||||||||
| ≥55℃ fan rotates | ||||||||||
| protection | over-load, over-discharge, short circuit, high temperature, reverse polarity | |||||||||
| communication | Rs232, Rs485, SNMP, APP etc(optional) | |||||||||
| temperature | -10℃~40℃ | |||||||||
| noise | ≤55db | |||||||||
| humidity | <95% | |||||||||
| note | All sbecification are subject to change without prior notice | |||||||||
